Portable BF9.9
PORTABLE, FUEL EFFICIENT, AND POWERFUL.
The BF8 offer more of what you want. More battery charging power. Easier to use features. Quieter performance. Dependable performance in a portable package. Better reliability.
Add in the optional Power Thrust design, and you’ve got an even more powerful and world-known Honda four-stroke motor, with 60% more thrust in reverse and 15% more in forward.
Teknik Özellikler
Engine Type:
4-Stroke SOHC 2 Cylinder/4 Valves
Displacement:
222 cc (13.5 cubic inches)
Bore & Stroke:
58 mm x 42 mm (2.3 x 17 inches)
Full Throttle RPM Range:
5,000-6,000 RPM
Rated Power:
9.9 HP @ 5,500 RPM
Cooling System:
Water Cooled
Fuel Delivery:
1 Carburetor
Ignition System:
PGM-IG
Starting System:
Electric/Recoil
Exhaust:
Through Hub
Lubrication:
Wet Sump
Trim Range:
5 Stage 4°-8°-12°-16°-20°
Tilt Range:
72°
Gear Ratio:
2.33:1
Gear Shift:
F-N-R
Alternator with voltage regulator (Electric Start):
12-Amp (148 watt)
Alternator with voltage regulator (Manual Start):
6-Amp (76 watt)
Propeller:
4-Blade Aluminum
Diameter x Pitch, Standard:
9¼ x 8 inches
Diameter x Pitch, Power Thrust:
10 x 6.5 inches
Power Tilt:
Available
Oil Pressure Alert:
Standard
Temperature Alert:
Standard
Rev-Limiter:
Standard
Overall Width:
345 mm/13.6 inches
TRANSOM HEIGHT S Type:
381 mm/15 inches
TRANSOM HEIGHT L Type:
508 mm/20 inches
TRANSOM HEIGHT X Type:
635 mm/25 inches
DRY WEIGHT S Type:
42 kg/92 lbs.
DRY WEIGHT L Type:
44 kg/98 lbs.
DRY WEIGHT X Type:
48 kg/107 lbs.
