Portable BF2.3
Özellikler
Dünyadaki en hafif ve en az yakıt tüketen 4-zamanlı dıştan takma
Motor üstünde 1 litre yakıt deposu
Gaz kolu ve dişli kavraması dümen kolunda olduğundan tek elle idare edebilme avantajı
Geniş ergonomik taşıma sapı
Sığ sular için özel seyir konumu
360° geniş manevra yeteneği
Teknik Özellikler
Engine Type:
4-Stroke OHV, 1 Cylinder/2 Valves
Displacement:
57.2 cc (3.49 cubic in)
Bore & Stroke:
45 mm x 36 mm (1.8 x 1.4 inches)
Full Throttle RPM Range:
5,000-6,000 RPM
Rated Power:
2.3HP (1.7 kW)
Cooling System:
Forced Air
Ignition System:
Transistorized
CARB Rating (California):
3-STAR, ultra low emission
Fuel:
Unleaded 86 octane
Fuel Tank Capacity:
.29 US gal (1.1L)
Starting System:
Recoil
Exhaust:
Under Water, Above Propeller
Lubrication:
Oil Slinger System
Trim Range:
4-Stage: 5°, 10°,15°, 20°
Tilt Range:
75°
Gear Ratio:
2.42:1
Steering Angle:
360° pivot
Propeller:
3-Blade Plastic
Diameter x Pitch:
7.25 x 4.75 inches
Overall Width:
285 mm / 11.2 in
TRANSOM HEIGHT S Type:
418 mm / 16.5 in
TRANSOM HEIGHT L Type:
571 mm / 22.5 in
DRY WEIGHT S-Type:
13 kg / 29.5 lbs
DRY WEIGHT L-Type:
14 kg / 31 lbs
Galeri
